•Front Panel LEDs indicate status conditions for maximum efficiency.
•Storage compartment for convenient access to spare parts and consumables.
•Versatile 1Torch with ATC disconnect makes it easy to add lead extensions or convert to a machine torch.
•True Guard roll bar provides easy transportation and protection for unmatched durability.
•Multi-voltage allows operation from 208 to 480 Volts in a single power supply.
•Auto Pilot Restart feature instantly reignites the pilot arc while cutting expanded metals.
•Lighter weight design for maximum portability.





Included Features Power Supply
50 ft. (15.2m) Lead
1Torch SL100, 75 deg. Head
10 ft. (3.0m) Input Power Cable, Work Cable without 20 Amp Plug (460V) and Clamp
Spare Parts Kit
Operating Manual
Process(es) Manual Air Plasma Cutting
Torch SL100 with ATC (hand)
Certifications IP23S
Industrial Applications Heavy Fabrication
Industrial Applications Manufacturing
Industrial Applications Contractors
Cut Capacity 1.25 in. (30mm) Recommended Cut
Cut Capacity 2.00 in. (50mm) Maximum Cut
Amperage Range 20-120 Amps
Input Power 208/230 - 460V 1/3 Phase 50/60 Hz
Input Power 400V 3 phase 50Hz
Input Power 600V 3 phase 50/60Hz
Weight 62 lbs (28.1kg)
Duty Cycle 60% @ 120A
Gas Type Air
Gas Pressure 70 psi (4.8 bar)
Gas Flow 7.5 cfm (212 lpm)
Pilot Start Cartridge
Control Hand Torch Switch or Hand Pendant Control
